Gridfinity skeleton baseplates press fit magnets 3D model preview
View source Save
26 downloads 0 likes 0 views Free price

About this 3D model

This is a light skeleton version that still has magnets of Zack Freedman's Gridfinity system: https://gridfinity.xyz/ It matches the Gridfinity spec, and should be compatible with any Gridfinity boxes and addons. Changes from original: - Skeleton version with minimal height to save filament and height - No screw holes or anyway to attach them together without super glue. - Magnet holes are 6.1mm x 2.1mm for a tight press fit, no super glue needed. - corners are not rounded to attach together and fit in corners nicer. - There's a hole on the bottom of the magnet so you can push the magnets back out if needed. It contains every model size from 1x1 to 6x6
