About this 3D model

All files can be found under the "Thing Files'' tab right below the photos of our hands. Please click download all file to get all components of the hands. For More information on assembly or the research, please go to http://www.cyborgbeast.org To make the Normal Hand Version, print and scale the following: 1x Right OR Left Palm 1x Normal Gauntlet or Normal Gauntlet w Tensioner 4x Finger Phal 4x Finger w Bumps OR Finger wo Bumps 1x Thumb Phalange 1x Thumb Finger w Bumps OR Thumb Finger wo Bumps To make the No Thumb Hand Version, print and scale the following: 1x R No Thumb Palm OR L No Thumb Palm 1x R One Hinge Gauntlet OR L One Hinge Gauntlet 4x Finger Phal 4x Finger w Bumps OR Finger wo Bumps Ulnar/Radial Deviation Hand, Movable Thumb Hand, and Cyborg Arm --> Soon to be released. Most voluntary closing devices including this design need sufficient wrist movement and strength for proper function. This design doesn't require Orthoplastic. The fingers are designed for better gripping and to avoid over extension of the proximal phalange and distal finger segment. It fits a 1 to 2 mm cabling and elastic bands. Acknowledgements: The Cyborg Beast is a remix of the snap together Robohand (http://www.thingiverse.com/thing:92937) and the original Robohand (http://www.thingiverse.com/thing:44150).
